The Ekko EB12E-98LI pallet stacker is a Lithium-Ion battery powered drive and lift electric pallet stacker that features adjustable width forks and legs allowing it to handle virtually any type of pallet or skid. This Ekko pallet stacker is ideal for moving and stacking pallets and skids. A 24v 50AH Li-ion battery and 110v integral charger come standard with the stacker. The metal mesh mast provides the user with a clear forward view. Ekko stacker features a 2,640 lb capacity at a 24” load center up to the 98" lift max. height, and a tight 52.6" turning radius for maneuverability in tight aisles. The ergonomic offset handle includes speed, lift/lower, auto-reverse safety belly button switch, and horn. A .75kW drive motor propels the stacker at 4.0 mph loaded and 4.2 mph empty. A 2.2kW lift motor raises loads at 3.6” per second loaded and 5.4” per second unloaded. The Ekko EB12E-98LI walkie stacker features all robotically welded steel construction for years of reliable service.
The EB12E-98LI Ekko walkie stacker normally leaves the warehouse in 3 to 5 business days.
Specifications:
- Capacity At 24" Load Center (48"L pallet with evenly distributed load): 2,640 LBS 2.6" to 98"
- 2.6" lowered fork height / 98" max. raised fork height
- 24v 50AH Li-ion battery with 110v integral charger are included
- Collapsed Mast height is 72" / Fully Extended Mast Height is 120"
- The recommended minimum isle width for right angle stacking is 75”
- Ergonomic handle contains throttle, forward/reverse controls, lift/lower controls, safety reversing belly switch, and horn
- 52.6" turning radius for use in tight areas
- Ground clearance is .95"
- Gradability: Max 6% loaded / 8% unloaded (forks must be lowered on slope)
- Curtis instrument controller, battery discharge indicator combination gauge
- Fork width adjusts from 8.3” O.D. to 33.5” O.D.
- Individual forks are 45” long x 3.9” wide x 1.38” thick
- Legs width adjusts from 45.7"W O.D to 59.1"W O.D.
- Infinitely variable speed operation from 0 mph to 4 mph empty and 0 mph to 4.2 mph loaded. Travel speed is constant regardless of load.
- Lift speed is 5.4 i.p.s. empty and up to 3.6 i.p.s. loaded
- Lower speed is 3.8 i.p.s. empty and up to 4.4 i.p.s. loaded
- Electro-magnetic braking for enhanced stopping power / Electronic neutral braking for accurate control
- Service Weight: 1300 LBS
- Warranty: 1 year limited
