Endura-Veyor Low Profile Slider Bed Conveyors - 18" Belt

Endura-Veyor Low Profile Slider Bed Conveyor
Endura-Veyor Low Profile Belt Conveyor shown with Optional Side Guides
Endura-Veyor Low Profile Conveyor shown with Optional Side Guides
Endura-Veyor Conveyor Colors
Click to see More Photos
Back to List
$4,456.25
SKU: LP213-18-6



Scroll Down for More Info
Additional Info

Endura-Veyor Low Profile Slider Bed Conveyors are designed to convey light weight items. These low-profile belt conveyors are ideal for placing beneath machinery, to catch scraps and offcuts, bulk parts and stampings. Endura-Veyor slider bed conveyors can be used in a variety of applications, including stamping press operations and plastic injection molding. The Endura-Veyor lo-pro is available in various different configurations with custom design options, designed to meet your applications needs. The frame is made of 12-gauge formed steel, welded in beds.

Belt widths from 3" to 25" available and belt lengths from 2' to 12' available - please request a quote if you require a belt width/length not shown. Stainless steel frame models available - please request a quote.


Controller and side guides are not included with conveyor, see optional fixed/variable speed controllers and side guides in options chart below.



Endura-Veyor Low Profile Conveyors are built to order with an estimated lead time to leave the warehouse of 12 to 16 weeks.



Specifications:

  • 18" wide clear urethane belt (belt widths from 3" to 25" available, quoted upon request)
  • 60, 90 or 100 LBS Live Load
  • Belt Lengths: 6', 9', or 12' - see models in chart below (belt lengths from 2' to 12' available, quoted upon request)
  • Overall frame height profile of 3⅜” to fit space-constricted areas (includes 1-3/8" tall flared steel side skirt)
  • Belt Speeds Available: 20 fpm, 25 fpm, 30 fpm, 40 fpm, 55 fpm, 80 fpm, & 115 fpm - select in chart below
  • 1/4 HP shaft mount drive motor
  • Voltages Available: 120V 1 PH, 208V 3 PH, 230V 3 PH, and 460V 3PH - select in chart below
  • Overall Unit Width: 20-3/16" to 30½" at the drive area
  • Assembled and tested prior to shipment



Options:

  • Start/Stop Controller (fixed speed) - Model EV-SSC
  • Variable Speed Controller 4:1 Ratio - Model EV-VSC
  • 10' Cord & Wall Plug for VSC or SSC - Model EV-PLUG
  • Side Guides to prevent product and debris from getting under the belt - Models with suffix -SG





Endura-Veyor Low Profile Conveyors:
SKUCapacity/Desc.LengthWeightPriceQty
LP213-18-660 LBS Live Load / 18" Wide Belt6'266 LBS $4,456.00
LP213-18-990 LBS Live Load / 18" Wide Belt9'327 LBS $5,375.00
LP213-18-12100 LBS Live Load / 18" Wide Belt12'388 LBS $6,063.00
Select Belt Speed & Voltage:
SKUCapacity/Desc.WeightPriceQty
EV2020 FPM Belt Speed0 LBS0.00
EV2525 FPM Belt Speed0 LBS0.00
EV3030 FPM Belt Speed0 LBS0.00
EV4040 FPM Belt Speed0 LBS0.00
EV5555 FPM Belt Speed0 LBS0.00
EV8080 FPM Belt Speed0 LBS0.00
EV115115 FPM Belt Speed0 LBS0.00
EV-120V1PH120V Single Phase Motor0 LBS0.00
EV-208V3PH208V 3-Phase Motor0 LBS0.00
EV-230V3PH230V 3-Phase Motor0 LBS0.00
EV-460V3PH460V 3-Phase Motor0 LBS0.00
Options:
SKUCapacity/Desc.WeightPriceQty
EV-SSCStart/Stop Controller0 LBS $1,313.00
EV-VSCVariable Speed Controller0 LBS $1,463.00
EV-PLUG10' Cord and Wall Plug5 LBS $188.00
LP213-18-6-SGSide Guides For Model LP213-18-610 LBS $141.00
LP213-18-9-SGSide Guides For Model LP213-18-910 LBS $163.00
LP213-18-12-SGSide Guides For Model LP213-18-1210 LBS $183.00
