Endura-Veyor LD 335 Light Duty Slider Bed Conveyors are designed to convey light weight items. These belt conveyors are ideal for use in prodution lines in various industries. Endura-Veyor slider conveyors can be used in a variety of applications, including stamping press operations and plastic injection molding. The Endura-Veyor light duty slider belt conveyor is available in various different configurations with custom design options, designed to meet your applications needs. The frame is made of 12-gauge formed steel, welded in beds.
Belt lengths from 10' to 25' are available - please request a quote if you require a belt length not shown. Stainless steel frame models available - please request a quote.
Controller and side guides are not included with conveyor, see optional fixed/variable speed controllers and side guides in options chart below.
Endura-Veyor LD 335 Light Duty Slider Bed Conveyors are built to order with an estimated lead time to leave the warehouse of 12 to 16 weeks.
Specifications:
- 12.5" wide black PVC belt; effective width 13"
- 175 LB Live Load
- Belt Lengths: 10', 15', 20', or 25'
- Overall unit width: 16-3/16" to 25-1/4" at the drive area
- Frame profile: 10-3/8;" high / 10-11/16" at drive - includes a 3" high side skirt
- Belt Speed is 65 fpm standard, but other speeds also available: 20 fpm, 40 fpm, 65 fpm & 107 fpm - please contact HOF for pricing
- 3/4 HP drive motor available in these voltages: 120V 1 PH, 208V 3 PH, 230V 3 PH, and 460V 3PH - select in chart below
- Assembled and tested prior to shipment
Options:
- Start/Stop Controller (fixed speed) - Model LD335-EV-SSC
- Variable Speed Controller 4:1 Ratio - Model LD335-EV-VSC
- 10' Cord & Wall Plug for VSC or SSC - Model LD335-EV-PLUG
- Side Guides to prevent product and debris from getting under the belt - Models with suffix -SG
