The Aardwolf DSA07 Drill Stand is engineered for professionals who demand stability, precision, and versatility in their drilling tasks. Designed with a powerful integrated vacuum base, this stand provides exceptional hold during operation, ensuring accuracy in every application. Whether you're using compressed air, an optional battery-powered vacuum pump, or an electric vacuum pump, vacuum can be easily applied to suit your needs. A sturdy 34mm round column features an 11-3/8" long-toothed rack, firmly secured for smooth vertical travel. This drill stand includes an integrated return spring with a locking button, making it ideal for repetitive, series drilling tasks. Precision is further enhanced by an adjustable scale ring that allows for accurate drilling depth adjustments down to the last millimeter. With a working height of 12", a drill support collar diameter of 1-3/4", and a convenient cable holder, the DSA07 maximizes operator efficiency and accuracy. Please note: the drill is not included with the stand.
.gif)
Aardwolf DSA07 Drill Stand is built to order with an estimated lead time to leave the factory of 2-3 business days.
Specifications
- Drill bore size: 2-3/8"
- Vacuum base dimensions: 7-7/8" x 8-1/8"
- Column diameter: 1-5/16" (34mm)
- Rack length: 11-3/8"
- Working height: 12"
- Drill support collar diameter: 1-3/4"
- Vacuum application options: Compressed air, battery-powered vacuum pump (optional), or electric vacuum pump
- Integrated return spring with locking button for series drilling
- Adjustable scale ring for precise drilling depth control
- Packaging dimensions: 22-7/8" L x 12-1/4" W x 9-1/2" H
- Net weight: 13 lb
